Testing the Use of Rails Caching

I was doing some performance work within a Rails application where expensive (computationally) data was being generated on each request. It was quick to implement the low-level caching that wrapped the expensive data generation. In this particular case, I wanted to ensure that the caching logic was valid as there were numerous conditions at play. I normally wouldn’t test caching if the cache key was something trivial (or automatic like using ActiveRecord#cache_key).

There are only two hard things in Computer Science: cache invalidation and naming things.

– Phil Karlton (source)

Peering into the Cache

This Rails application had the cache_store set to :memory_store in the test environment. We wanted to make sure that our tests were still going through the same code paths as would happen in production.

# config/environments/test.rb:
Rails.application.configure do
  config.cache_store = :memory_store
end

The inner data structure of ActiveSupport::Cache::MemoryStore is not publically accessible.

[1] pry(main)> Rails.cache.write('my-cache-key', 'my-value')
=> true
[2] pry(main)> Rails.cache
=> <#ActiveSupport::Cache::MemoryStore entries=1, size=260, options={}>
[3] pry(main)> ls Rails.cache
ActiveSupport::ToJsonWithActiveSupportEncoder#methods: to_json
ActiveSupport::Dependencies::ZeitwerkIntegration::RequireDependency#methods: require_dependency
ActiveSupport::Cache::Store#methods: delete  exist?  fetch  fetch_multi  logger  logger=  mute  options  read  read_multi  silence  silence!  silence?  write  write_multi
ActiveSupport::Cache::MemoryStore#methods: cleanup  clear  decrement  delete_matched  increment  inspect  prune  pruning?  synchronize
instance variables: @cache_size  @data  @key_access  @max_prune_time  @max_size  @monitor  @options  @pruning
class variables: @@logger

The raw data is held in the instance variable @data. We can reach in and grab that to perform some inspections:

[4] pry(main)> Rails.cache.instance_variable_get(:@data)
=> {"my-cache-key"=>#<ActiveSupport::Cache::Entry:0x00007f8ade4da858 @created_at=1580064434.3177679, @expires_in=nil, @value="my-value", @version=nil>}

The caveat of this approach is clear, as we’re reaching into the private space of the Rails cache.

Creating the Helper

I wanted to make it easier for myself and others to test Rails caching in this project. Creating a test helper is ideal as all the tests can reach for the built utilities when testing code related to caching.

We’ll create a new test helper, that can be included in our test/test_helper.rb:

# test/support/rails_cache_helper.rb:
module RailsCacheHelper
  def with_clean_caching
    Rails.cache.clear
    yield

  ensure
    Rails.cache.clear
  end

  def cache_has_value?(value)
    cache_data.values.map(&:value).any?(value)
  end

  def key_for_cached_value(value)
    cache_data.values.each do |key, entry|
      return key if entry&.value == value
    end
  end

  private

  def cache_data
    Rails.cache.instance_variable_get(:@data)
  end
end

This helper gives us three utilities:

1. The with_clean_caching method, which purges the cache before and after the block is executed. It is worth noting that the :memory_store is only purged at the end of the test suite.
2. The cache_has_value?(value) method, which returns a boolean if the cache has the specified value.
3. The key_for_cached_value(value) method, which returns the key that can be used to look up the specified value.

With these new methods, it was much easier to test the caching code. There was no need to do any fancy stubbing and/or using mock objects.

Note: there are more features that can be expanded upon in this helper:

• Working with the meta-data on cache entries (e.g., expires_in).
• Custom assertions (e.g., assert_cached(value)).

Testing Rails Caching

Now I was able to test the caching specifically. I wrapped my tests in with_clean_caching as these tests were specific about using caching. I could have also approached this by making it so the cache is purged before each test (e.g., setup(), before(:each)), but I didn’t opt for that right now.

The following is a contrived example, but you could imagine that the cache key is generated much deeper in the application code. This makes it difficult to get the cache key to then inspect and make assertions about the cached data.

Using RailsCacheHelper (that we created above), we can make use of #cache_has_value? and #key_for_cached_value to make assertions based on the returned value without needing to know the cache key.

# test/caching_test.rb
class CachingTest < ActiveSupport::TestCase
  test 'caching works' do
    with_clean_caching do
      # bunch of test setup ...

      result = Caching.expensive_call(some_object, data_structure, request_data)

      assert(cache_has_value?(result))
    end
  end

  test 'caching is not used if request header specifies caching=false' do
    with_clean_caching do
      # bunch of test setup, and adding caching=false in request_data ...

      result = Caching.expensive_call(some_object, data_structure, request_data)

      assert(cache_has_value?(result))
    end
  end

  test 'cache varies correctly based on object' do
    with_clean_caching do
      # bunch of test setup ...

      original_result = Caching.expensive_call(some_object, data_structure, request_data)
      original_key = key_for_cached_value(original_result)

      # setup different_object

      changed_object_result = Caching.expensive_call(different_object, data_structure, request_data)
      changed_object_key = key_for_cached_value(changed_object_result)

      rufute_equal(original_key, changed_object_key)
    end
  end

  test 'cache varies correctly based on data structure' do
    with_clean_caching do
      # pretty much same as the last test but varying the data structure
    end
  end

  test 'cache varies correctly based on request data' do
    with_clean_caching do
      # pretty much same as the last test but varying the request_data
    end
  end
end

Note that this approach worked for me, however, there are many different ways to test Rails caching. For example, this StackOverflow answer suggests making an InspectableMemoryStore which subclasses ActiveSupport::Cache::MemoryStore.
